SPECIFICATIONS

Brand Name: ELECAPITAL
Certification: CCC
Choice: yes
EU LVD Voltage: Low voltage: Below 50Vac or 75Vdc
Features: 3 position
High-concerned chemical: None
Item Type: SWITCHES
Material: Plastic
Model Number: RK2
Origin: Mainland China
Switch Type: Knob switch
Warranty: 2 years
semi_Choice: yes

Rated Voltage and Current:6A 250VAC/10A 125VAC
Contact Resistance:≤50mΩ
Insulation Resistance:≥100mΩ
Dielectric intensity:≥1500VAC/1min(50Hz)
Environmental temperature:-55～+85℃
Working Life:≥10000 Cycle
